Ref. : LA390

LA390
LA390
Interchangeable with: E1564. Material: 2.0401 – DIN 9835. They serve to pre-stress the spring or during stacking.

Made in Europe

NomCode LugandPrice
SPRING BLACK 70 D 16X 6,5X 12 LA39044917801,40
SPRING BLACK 70 D 16X 6,5X 16 LA39044917821,40
SPRING BLACK 70 D 16X 6,5X 20 LA39044917841,50
SPRING BLACK 70 D 16X 6,5X 25 LA39044917862,10
SPRING BLACK 70 D 20X 8,5X 16 LA39044917881,80
SPRING BLACK 70 D 20X 8,5X 20 LA39044917901,80
SPRING BLACK 70 D 20X 8,5X 25 LA39044917922,10
SPRING BLACK 70 D 20X 8,5X 32 LA39044917942,30
SPRING BLACK 70 D 25X10,5X 20 LA39044917962,40
SPRING BLACK 70 D 25X10,5X 25 LA39044917982,40
SPRING BLACK 70 D 25X10,5X 32 LA39044918002,60
SPRING BLACK 70 D 25X10,5X 40 LA39044918023,00
SPRING BLACK 70 D 32X13,5X 32 LA39044918043,10
SPRING BLACK 70 D 32X13,5X 40 LA39044918064,00
SPRING BLACK 70 D 32X13,5X 50 LA39044918084,40
SPRING BLACK 70 D 32X13,5X 63 LA39044918105,00
SPRING BLACK 70 D 40X13,5X 32 LA39044918123,90
SPRING BLACK 70 D 40X13,5X 40 LA39044918144,90
SPRING BLACK 70 D 40X13,5X 50 LA39044918165,60
SPRING BLACK 70 D 40X13,5X 63 LA39044918186,60
SPRING BLACK 70 D 40X13,5X 80 LA39044918207,60
SPRING BLACK 70 D 50X17X 32 LA39044918224,40
SPRING BLACK 70 D 50X17X 40 LA39044918245,60
SPRING BLACK 70 D 50X17X 50 LA39044918265,70
SPRING BLACK 70 D 50X17X 63 LA39044918289,00
SPRING BLACK 70 D 50X17X 80 LA390449183010,70
SPRING BLACK 70 D 50X17X100 LA390449183212,40
SPRING BLACK 70 D 63X17X 32 LA39044918346,90
SPRING BLACK 70 D 63X17X 40 LA39044918368,40
SPRING BLACK 70 D 63X17X 50 LA390449183810,70
SPRING BLACK 70 D 63X17X 63 LA390449184011,60
SPRING BLACK 70 D 63X17X 80 LA390449184215,50
SPRING BLACK 70 D 63X17X100 LA390449184418,90
SPRING BLACK 70 D 63X17X125 LA390449184622,40
SPRING BLACK 70 D 80X21X 32 LA390449184810,30
SPRING BLACK 70 D 80X21X 40 LA390449185013,40
SPRING BLACK 70 D 80X21X 50 LA390449185215,60
SPRING BLACK 70 D 80X21X 63 LA390449185418,30
SPRING BLACK 70 D 80X21X 80 LA390449185623,00
SPRING BLACK 70 D 80X21X100 LA390449185827,00
SPRING BLACK 70 D 80X21X125 LA390449186033,50
SPRING BLACK 70 D100X21X 32 LA390449186216,00
SPRING BLACK 70 D100X21X 40 LA390449186425,00
SPRING BLACK 70 D100X21X 50 LA390449186629,00
SPRING BLACK 70 D100X21X 63 LA390449186834,00
SPRING BLACK 70 D100X21X 80 LA390449187048,00
SPRING BLACK 70 D100X21X100 LA390449187258,00
SPRING BLACK 70 D100X21X125 LA390449187480,00
SPRING BLACK 70 D125X27X 32 LA390449187632,00
SPRING BLACK 70 D125X27X 40 LA390449187839,00
SPRING BLACK 70 D125X27X 50 LA390449188061,00
SPRING BLACK 70 D125X27X 63 LA390449188262,00
SPRING BLACK 70 D125X27X 80 LA390449188478,00
SPRING BLACK 70 D125X27X1004491886104,00
SPRING BLACK 70 D125X27X125 LA3904491888115,00
SPRING BLACK 70 D125X27X160 LA3904491890142,00
